Produktbeskrivning

InfraStruXure Central provides an efficient way for organizations to monitor their company-wide multi-vendor physical infrastructure: power, cooling, security, and environment. Real-time monitoring, user-defined reports and graphs, and instant fault notification and escalation enable quick assessment and resolution of critical infrastructure events that can adversely affect IT system availability. This centralized repository of critical information can be accessed by multiple users from anywhere on the network, creating a consolidated view of the physical infrastructure.

InfraStruXure Central Basic scales up to 525 devices and 15 surveillance cameras. It supports capacity management up to 20 racks and change management up to 1000 IT assets.



Egenskaper

● Alarm filters
● Auto-discovery
● Capacity Manager add-on application
● Centralized alert repository
● Centralized management
● Change Manager add-on application
● Custom mapping
● Custom reporting
● Customizable user access
● Encrypted communications
● Extendable architecture
● Fault notification
● Free text search
● Graphical trending analysis
● Integrated data storage
● Multi-vendor device support
● Private networking
● Real-Time Monitoring (RTM)
● Remote monitoring support
● Surveillance add-on application
● Unified console



Teknisk specifikation

Typ av enhet	Enhet för nätverksadministration
Bredd	48.3 cm
Djup	38.1 cm
Höjd	4.4 cm
Vikt	9.6 kg
Färg	Svart

RAM	1 GB
Hårddisk	HDD 160 GB x 1

Formfaktor	Kan monteras i rack
Datalänkprotokoll	Ethernet, Fast Ethernet, Gigabit Ethernet
Nätverks/transportprotokoll	TCP/IP, DNS
Protokoll för administration på distans	SNMP, HTTP, HTTPS
Krypteringsalgoritm	SSL

Gränssnitt	2 x 1000Base-T - RJ-45 1 x PS/2-tangentbord 1 x PS/2-mus 2 x USB - Type A 1 x VGA 1 x RS-232 - DB-9

Nätdel	Intern strömförsörjning

Operativsystem erfordras	Microsoft Windows Server 2003, Microsoft Windows 2000 SP4, Microsoft Windows XP SP2, Microsoft Windows Vista, Red Hat Enterprise Linux 5

Service och support	Begränsad garanti - 2 år

Min temperatur vid drift	10 °C
Max temperatur vid drift	35 °C
Luftfuktighet vid drift	5 - 90%

Designat för

P/N: ACDC2513, ACF600, AP5607, AP7950B, AR203A, AR204A, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3100G, AR3100SP, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3103SP, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106SP, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150SP, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3810, AR3812, AR4000MV, AR4000MVX429, AR4000MVX432, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X432, NBPD0160A, NBPD0171, NBWL0355A, NBWL0356A, SCL400RMJ1U, SCL500RM1UC, SCL500RM1UNC, SCL500RMI1UC, SCL500RMI1UNC, SMC1000-BR, SMC15002U-BR, SMC1500I-2U, SMC1500I2U-BR, SMC1500I-2UC, SMC1500I-BR, SMT3000I2U-BR, SMTL1000RM2UC, SMTL1000RMI2UC, SMTL750RM2UC, SMTL750RMI2UC, SMX2000LV, SMX2000LVNC, SMX2000LVNCUS, SMX2000LVUS, SMX2200R2HVNC, SMX3000HV-BR, SMX3000HVT, SMX3000HVTUS, SMX3000LV, SMX3000LV2U-BR, SMX3000LVUS, SRT1000RMXLA, SRT1000RMXLA-NC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT1500RMXLA, SRT1500RMXLA-NC, SUA2200R3XLNETPKG, SUA3000R3XLNETPKG, SUA3000RMXL3U-BR, SURT3000XLI-ET, SURT5000XLIX438, SYAF8KRMTX424
