Produktbeskrivning

These affordable Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of mobile, IoT and mobility requirements. With a maximum aggregate data rate of 1.77 Gbps (1.774 Gbps), they deliver the speed and reliability needed for venues and workplaces such as schools, midsize offices and retailers.



Egenskaper

Multi-user M1M0 (MU-MIMO)
The 500 Series AP supports downlink MU-MIMO just like Wi- Fi 5 APs. The added benefit is the ability to multiply the number of clients that can now send traffic, thus optimizing client-to-AP spatial stream diversity.

Wi-Fi 6 and MU-MIMO aware client optimization
Aruba's patented AI-powered ClientMatch technology eliminates sticky client issues by placing Wi-Fi 6 capable devices on the available AP. Session metrics are used to steer mobile devices to the AP based on available bandwidth, types of applications being used and traffic type - even as users roam.

Aruba Advanced Cellular Coexistence (ACC)
This feature uses built-in filtering to automatically minimize the impact of interference from cellular networks, distributed antenna systems (DAS), and commercial small cell or femtocell equipment.

Intelligent Power Monitoring (IPM)
Aruba APs continuously monitor and report hardware energy consumption. They can also be configured to enable or disable capabilities based on available PoE power - ideal when wired switches have exhausted their power budget.

Green AP energy efficiency
Aruba Wi-Fi 6 APs utilize analytics from NetInsight to automatically transition in and out of a sleep mode based on client density.

VPN Tunnels
In Remote AP (RAP) and IAP-VPN deployments, the Aruba 500 Series can be used to establish a secure SSL/IPSec VPN tunnel to a Mobility Controller that is acting as a VPN concentrator.

Trusted Platform Module (TPM)
For enhanced device assurance, all Aruba Aps have an installed TPM for secure storage of credentials and keys, and boot code.

Simple and secure access
To simplify policy enforcement, the Aruba 500 Series uses Aruba's policy enforcement firewall (PEF) feature to encapsulate all traffic from the AP to the Mobility Controller (or Gateway) for end-to-end encryption and inspection. Policies are applied based on user role, device type, applications, and location. This reduces the manual configuration of SSIDs, VLANs and ACLs. PEF also serves as the underlying technology for Aruba Dynamic Segmentation.

High-density connectivity
Each 500 Series AP provides connectivity for a maximum of 256 associated clients per radio. In real-world scenarios, the maximum recommended client density is dependent on environmental conditions.



Teknisk specifikation

Typ av enhet	Trådlös åtkomstpunkt
Robust design	Inomhus

Formfaktor	I taket
Anslutningsteknik	Trådlös
Dataöverföringshastighet	1.2 Gbps
Linjekodningsformat	CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
Datalänkprotokoll	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Metod för spridningsspektrum	OFDM, DSSS, OFDMA
Frekvensband	2.4 GHz, 5 GHz
Prestanda	Maximal datahastighet (2,4 GHz): 574 Mbps Maximal datahastighet (5 GHz): 1,2 Gbps Aggregatgenomströmning: 1,774 Gbps
Kapacitet	Trådlösa klienter per trådlös radio: 256 BSSID:er per radio: 16 OFDMA-enheter: 8
Statusindikatorer	System, status
Funktioner	Auto-uplink (auto MDI/MDI-X), ingående paketinspektion (DPI), Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), redo för strålformssändning (TxBF), Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Advanced Cellular Coexistence (ACC), ClientMatch, cyklisk växlingsmångfald (CSD), MU-MIMO-teknik, paketaggregering A-MPDU, paketaggregering A-MSDU, SU-MIMO-teknologi, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), stöd för hög genomströmning (HT), LED av-läge, EEE (Energy-Efficient Ethernet), Orthogonal Frequency Division Multiplexing (OFDM), 2x2 MIMO-teknik, stöd för mycket hög genomströmning (VHT) support, säkerhetslås (kompatibel med Kensington-säkerhetslås), Orthogonal Frequency Division Multiple Access (OFDMA), högeffektiv support (HE), målväntetid (TWT)
Krypteringsalgoritm	SSL, WPA, WPA2, WPA3
Standarder som följs	IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6

Antenn	Inbyggd
Antal antenner	2
Riktning	Rundstrålande
Förstärkningsnivå	5.7 dBi

Kompatibel med Internet of Things (IoT)	Ja
Kommunikationsteknologi	Bluetooth Low Energy (LE), Zigbee

Gränssnitt	1 x 1000Base-T - RJ-45 1 x USB 2.0 - Type A 1 x konsol - micro-USB

Inkluderade tillbehör	Monteringsfäste
MTBF (genomsnittstid mellan fel)	148 år
Standarder som följs	UL 2043, FCC, EN 60601-1-1, CE/EMC, Directive 2014/35/EU, Directive 2014/30/EU, ISED, Directive 2014/53/EU, IEC/EN/UL 60950, ETS 300 019 Class 2.3, ETS 300 019 Class 1.2

Stöd för PoE (Power Over Ethernet)	PoE
Energiförbrukning vid drift	8.9 Watt

Operativsystem erfordras	ArubaOS, InstantOS

Emballagets bredd	19.3 cm
Emballagets djup	18.3 cm
Emballagets höjd	6.3 cm
Emballagets vikt	645 g

Service och support	Begränsad garanti - livstid

Min temperatur vid drift	0 °C
Max temperatur vid drift	50 °C
Luftfuktighet vid drift	5 - 93 % (icke-kondenserande)
